| Power Source |
Corona- 200~240V, 50/60Hz, 1P
Primer-380~415V, 50/60Hz, 3P |
| Power Consumption |
Corona-2Kw, Primer-9Kw |
| High Frequency output |
7KV |
| Operating Frequency |
20~50Khz |
| Recifier |
IGBT Type |
Operating system
|
Conventional button |
| Max. Generating Bar Length |
520mm |
| H.V Cable |
|
Standard Type of
Generating bar |
Ceramic bar |
| Standard dielectric substance |
Silicone roll |
|
| Dielectirc substance roll width |
600mm |
| Working width |
520mm |
| Heater power |
8Kw |
| No. of Tank |
2개2 tanks |
| Automatic primer pump |
circulation type |
| Stop & Automatic self-cleaning |
|
| Line Speed |
30meter/min |
| Coating system |
Silicon roller coating |
| Dimension(Corona + Primer) |
L 2200 x W 870 x H 1050mm |
| Weight(Corona + Primer) |
Abt. 300Kgs. |
|
